x86 and x64 Assembly from Scratch

🎯 Objective

To gain a deep, foundational understanding of how x86 and x64 assembly work, from CPU registers and calling conventions to memory addressing and function calls. This is critical for exploit developers who need precise control over memory, registers, and the instruction pointer.

1. Why Learn Assembly for Exploitation?

Exploit developers operate close to the metal — at the point where programming languages are compiled into instructions the CPU can directly understand. Memory corruptions, ROP chains, shellcode, and low-level payloads require understanding register state, stack layout, and control flow.

In exploit development:

• You overwrite EIP or RIP
• You pivot the stack (ESP or RSP)
• You inject shellcode and need to place arguments in registers or memory
• You must understand how values are passed and returned at the assembly level

2. Architecture Overview: x86 vs x64

2.1 x86 (32-bit)

• 4-byte registers (e.g., eax, ebx)
• 4GB virtual address space
• Arguments passed via stack
• Used in legacy applications or 32-bit systems

2.2 x64 (64-bit)

• 8-byte registers (rax, rbx)
• 64-bit pointers, more addressable memory (up to 18 exabytes)
• First 4 arguments passed in registers (Windows: rcx, rdx, r8, r9)
• Return values in rax

2.3 Register Subdivisions

Example (x64):

Register:         rax (64-bit)
 ├── eax (32-bit)
 │   ├── ax (16-bit)
 │       ├── ah (8-bit high)
 │       └── al (8-bit low)

3. Register Classifications

4. Instruction Types and Syntax (Intel Style)

4.1 Syntax Format

instruction destination, source

4.2 Common Instructions

5. Addressing Modes and Operand Types

5.1 Addressing Types

5.2 Operand Sizes

• BYTE PTR [mem]: 8-bit
• WORD PTR [mem]: 16-bit
• DWORD PTR [mem]: 32-bit
• QWORD PTR [mem]: 64-bit

6. Memory Layout and Stack Anatomy

Typical process memory layout:

0xFFFFFFFF  ← Stack Top (grows down)
     |
     | Stack (local vars, return addr)
     |
     | Heap (malloc/calloc/free - grows up)
     |
     | BSS (uninitialized globals)
     |
     | Data (initialized globals)
     |
     | Text (code, .text segment - executable)
0x00000000  ← Null page

7. Calling Conventions

7.1 cdecl (x86 Linux default)

• Arguments pushed right-to-left
• Return value in eax
• Caller cleans stack

7.2 stdcall (Windows APIs)

• Callee cleans stack

7.3 fastcall (Microsoft optimized)

• Some args in registers (e.g., ecx, edx)

7.4 System V AMD64 ABI (Linux x64)

• Return: rax

7.5 Windows x64 Calling Convention

8. Function Prologue and Epilogue

x86 Example

push ebp
mov ebp, esp
sub esp, XX         ; allocate space
...
mov esp, ebp
pop ebp
ret

Why It Matters

• Stack frames are key for local variables
• Exploits often overwrite saved EIP/RIP on stack

9. Flags Register (EFLAGS/RFLAGS)

Used with:

• cmp, test, je, jg, jl, jne, jz, jnz

10. Interrupts and Syscalls

Linux (x86):

mov eax, 1   ; syscall number: exit
mov ebx, 0   ; exit code
int 0x80     ; software interrupt

Linux (x64):

mov rax, 60  ; syscall: exit
mov rdi, 0   ; exit code
syscall

11. Loop and String Instructions

Looping

mov ecx, 10
loop_label:
; code
loop loop_label  ; decrements ecx, jumps if ecx != 0

String Instructions (with REP prefix)

• movsb, movsw, movsd
• cmpsb, stosb, scasb, lodsb
• rep, repe, repne

12. Writing Inline Assembly in C

int a = 5, b = 3, result;
__asm__(
    "movl %1, %%eax;"
    "addl %2, %%eax;"
    "movl %%eax, %0;"
    : "=r"(result)
    : "r"(a), "r"(b)
    : "%eax"
);

13. Compiling and Running Pure Assembly

hello.asm (NASM + Linux)

section .data
    msg db "Hello!", 0xA
    len equ $ - msg

section .text
    global _start

_start:
    mov eax, 4
    mov ebx, 1
    mov ecx, msg
    mov edx, len
    int 0x80

    mov eax, 1
    xor ebx, ebx
    int 0x80

nasm -f elf hello.asm
ld -m elf_i386 hello.o -o hello
./hello

14. Reverse Engineering and Disassembly

Use objdump, Ghidra, or radare2:

objdump -d binary
gdb ./binary

Look for:

• Function prologue: push ebp; mov ebp, esp
• Function calls: call 0x08048400
• Stack usage: mov eax, [ebp+0x8]

15. Tools and Emulators

✅ Summary

• Assembly allows direct control of CPU and memory.
• Key registers (eax, esp, eip) are critical for understanding control flow and payload placement.
• Stack frames, calling conventions, and memory addressing are the basis of buffer overflows and ROP chains.
• Tools like NASM, GDB, x64dbg, and Ghidra will help analyze and write exploits.
